| Date of Review |
June 2007 |
| Manufacturer |
DML |
| Subject |
Pzkpfw.VI Ausf.E Sd.Kfz.181 Tiger I Late Production 3-in-1 Kit |
| Scale |
1/35 |
| Kit Number |
6253 |
| Primary Media |
720 parts (590 parts in grey styrene, 104
etched brass, 21 clear styrene, 2 DS track runs, 2 twisted
steel wires, 1 spring) |
| Pros |
Molds cleaned up and improved once more;
DS tracks solve the tedium of single link track assembly; choice
of detail parts |
| Cons |
Fifth Tiger from DML (and second "late" version)
may muddy the waters and confuse modelers; still no zimmerit
on hull or turret |
| Skill Level |
Intermediate |
| MSRP (USD) |
$44.95 |
There is a point in life when the number of versions of a specific
vehicle offered tend to boggle the mind of the average modeler;
in the words of Al Capp's famous mountaineer, Li'l Abner, "it's
cornfusin'." Such is the case for most of us when it comes
to DML's Tiger releases.
There are now five of them on the market based on availability
(at least one is "sold out") and as near as I can figure
it looks like this:
| Kit Number |
Production variants |
Release Date |
Parts in kit |
Price |
| 6252 |
Initial |
Jan 2005 |
756 |
$32 |
| 6253 |
Late |
Jul 2005 |
1,134 |
$45 |
| 6286 |
Initial - DAK |
Oct 2005 |
950 |
$45 |
| 6350 |
Early "Wittmann" |
Nov 2006 |
1,053 |
$100 |
| 6406 |
Late |
Jun 2007 |
720 |
$45 |
Most kits were "3-in-1" kits, but in this case the
choice was basically a line tank, company commander, or battalion/regimental
commander based on radio antennas. This new kit is also a "3-in-1" with
the same level of options and command antennas. The "Initial" production
ones were either the dual "saddlebag" bin ones used
near Leningrad or single bin "common" versions with "Fiefel" air
cleaners. The "Early" Wittman tank was a special release "boutique" version,
but the late ones have the final "Steel Wheels" vice
the "Rubber Tired" wheels and a number of detail options
for specific sub-variants based on build date.
The main difference between the kits other than their variant
was the inclusion of either more or less etched brass (five frets
being the maximum noted), figures, and the use of regular, "Magic
Track" links or now the much simpler DS plastic runs. Some
purists have already squawked about the latter, but many modelers
have found out the hard way to be careful what you wish for, as
single link tracks, some consisting of as many as five parts a
link, may look good but are incredibly boring and tedious to build,
plus generally quite fragile on top of it. The DS plastic looks
good, takes paint well, and glues with common plastic solvents;
it also permits undercutting such as the pin ends of the track
and even open teeth to replicate castings as is the case here.
Overall, cleanup is simple and I do believe most people will like
these better. The two "sag guides" from previous kits
are included so you can get a good fit over the wheels with the
tracks.
There are a great number of options with the kit: two styles of
idlers, two different rear plates, three different mantelets, two
different turret roofs, two different commander's cupolas, two
different muzzle brakes – the list goes on. As before a partial
interior is included for the engine compartment as well as all
of the torsion bars and the 8.8 cm gun breech in the turret.
There are still some oddities, such as no zimmerit yet even though
it has been provided on the 1/72 versions of this tank. I suppose
some modelers prefer doing their own and matching a specific tank,
but for the majority providing it would make life easier. While
the mount for the AA MG is provided, no machine gun is provided
in the kit once again.
I noted changes in only three of the sprues that came with the
kit from the previous "late" version, but DML has once
again included a four page "brag book" as to what has
been done to the kit. They state they have redone the mufflers
and armored covers for the rear plate, fixed some problems with
the turret escape hatch, redone the hull shell to make more use
of "Slide Molding" features, and provided for the use
of a engine pre-heater (read blowtorch) at the rear of the hull.
However, if you wish to use that you will have to either knock
one together from scratch or use the one in the VW Starter kit
that DML just released.
The amount of etched brass has been reduced, and my take on that
is that the molds have all been "tweaked" a bit to clean
up earlier problems and thus much of the brass detailing is now
superfluous.
The kit comes with a nice sheet of targeted Cartograf decals and
a choice of one of six different finishing options, all but one
in a variety of late war tricolor schemes: "334", 1./s.Pz.Abt.
505, Nowe Koszary 1944 (green over Panzerbraun); "122",
1.s. SS-Pz.Abt. 101, Normandy 1944; "242", 2./s. SS-Pz.Abt.
102, France 1944; "304", 3./s SS-Pz.Abt. 101, Normandy
1944; "933," 9./s. SS-Pz.Regt. 3, 3rd SS Panzer Division "Totenkopf",
Poland 1944; and "133", 1./s. H. Pz.Abt. 510, Kovno 1944.
Technical assistance and research for this kit came from David
Byrden, Tom Cockle and Gary Edmundson.
Overall it is a nice kit and simpler to assemble due to the lesser
amounts of brass and single-section track runs, but I am not sure
how many more Tigers the market can absorb with relatively minor "tweaks" between
kits or choices of options.
Thanks to Freddie Leung for the review sample.
Sprue Breakout
- A 26 (Tiger I generic) 8.8 cm gun
- B 40 (Tiger I generic) drivers and idlers
- C 39 (Tiger I Late) fenders and alternate drivers
- D 30 (Tiger I Late) turret
- E 35 (Tiger I Late) turret roofs and optional details
- F 12 (Tiger I Late) hull sternplates
- G 31 x 2 (Tiger I Late) Steel road wheels
- g 4 (Command antenna) star type
- H 54 x 4 (Tiger I Late) torsion bars and single track links
- J 39 (Tiger I generic) interior components
- K 12 (Tiger I Late) hull roof and grilles
- L 2 (Command antenna) whip type
- L 12 (Tiger I generic) clear blocks
- MA 99 Etched brass (Tiger I Late)
- MB 1 Spring
- MB 1 Prebent wire
- MB 4 etched brass
- MB 1 Preformed etched brass
- N 2 (Command antenna) whip type
- P 39 (Tiger I Late) hull sides and cable details
- R 15 (Tiger I Late) turret stowage bin
- S 9 (Tiger I Late) clear
- U 2 (Tiger I Late) cupolas with or w/o rain gutters
- TA 5 (German OVM) pioneer tools
- TB 9 (German OVM) jack and hooks
