T-34/76 Mod.1942 Formochka

DML 1/35 T-34/76 Mod.1942 Formochka - Smart Kit First Look

By Cookie Sewell

Date of Review August 2009 Manufacturer DML
Subject T-34/76 Mod.1942 Formochka - Smart Kit Scale 1/35
Kit Number 6487 Primary Media 385 in grey styrene, 160 “Magic Track” links, 85 etched brass, 3 clear styrene, 2 twisted steel wire
Pros Another popular T-34 variant appears as a kit; kit provides a good version of a mid-production Factory No. 183 hull for this turret Cons Not found in any history of the T-34; no cupola for late-production variant offered
Skill Level Intermediate MSRP (USD) $49.95

First Look

Even though the Soviets quickly decided on producing two versions of the Model 1941 T-34 turrets – cast and welded – even with new casting techniques using steel molds they were hard pressed to keep up with production requirements. Another source of turrets was required. As a result, in October 1942 the State Committee on Defense (GKO) ordered the UZTM factory to produce pressed steel turrets as they could double the speed of production by this method.

The new turret design – called “Shtampovannaya Bashnya” or the pressed turret – was based on the cast turrets from Factory No. 183, but here the UZTM used its 10,000 ton “Shleman” steel press (which had been used to make components for destroyers and other warships) to produce the new turrets from 45mm homogenous rolled armor plate. Under the direction of chief designer L. Ye. Gorlitskiy it was hoped the design would use 60mm plate, but the press could not handle this and thus 45mm plate was used. Surprisingly during testing it was found to be superior in protection to the then standard 52mm cast turret armor.

UZTM produced both the cast turrets as well as the pressed steel turrets in parallel and sent out to other T-34 factories for production, but most commonly they were seen on Factory No. 112 (Krasnoye Sormovo) chassis. When production ceased on 1 March 1944 UZTM had produced between 2,050 and 2,062 of these turrets. They were used for both regular T-34 Model 1942 tanks as well as the Model 1943 with the commander’s cupola.

This tank has always been a popular variant of the T-34 due to its unique turret shape, and now DML has released a modified version of their Model 1942 “Gayka” kit with this turret. The name “Formochka” puzzles me, for it is not used by any contemporary Russian source nor any modern Russian historian, but only as a slang term (also used for “vacuform” as well) on Russian modelers’ websites. This is not the first time DML has done this, and while not as dim as the use of German names or designators for Soviet tanks it is still unfortunate.

Be that as it may, the kit provides all of the recent Model 1942 “Gayka” parts with six new moldings for the pressed steel turret. The rest of the turret bits are retained, but no aluminum barrel is provided. The roof parts are integral and unlike some recent DML M4 Shermans a new and proper base is provided.

The kit adds several new sprues to the latest set of the molds and provides the cast wheels, cast wheels with rubber tires, new stern plate, new radiator exhaust grilles, and the turret and detail components. The shapes and angles match the Russian plans of the tank I have on hand. A new set of 500mm “waffle” tracks are provided in the form of a new set of “Magic Link” single link tracks. Each link does come with two ejection pin marks on the inner face, but these stand proud and while tedious are easily removed.

As noted many older but well-done parts are used in this kit. The late-model double bump stops on the lower hull molding are still present, as previously noted they can’t really be seen when the model is assembled and is a“so what” correction.

The model comes with two standard PT periscopic sight/viewer with the “acorn” shaped cover found on most T-34s as well as the “cylinder” one seen on some tanks for the loader. A gun breech and partial interior to the turret are provided as with all of the DML T-34 kits. As noted the kit does not provide the late-model commander’s cupola, but one could be adapted from a Tamiya T-34 Model 1943 kit. Note that these tanks could and did carry external fuel tanks, with one each going on the rear sides of the tank and two smaller ones on the stern plate; it is recommended you try to get copies of “T-34 Snizhu Doverkhu” by Sergey Kirsanov (Frontline Illustrated, a Russian magazine) if possible to see how these attach.

This project is listed as supervised by Hirohisa Takada, with drawings from Minoru Igarashi and the Dragon design team; technical assistance was provided by Nick Cortese.

Three different finishing directions are provided: Unidentified Unit, Eastern Front 1944 (4BO green with earth brown patches, white 248); Unidentified Unit, Eastern Front, 1943 (whitewash over 4BO green, no markings); and the inevitable captured vehicle, Pz. Regt. 2nd SS Panzer Division “Das Reich”, Kursk 1943 (sand and green, white outline crosses and white 1011). A targeted set of Cartograf decals are provided.

Overall, this is a nice execution of this variant of the T-34 and other than the unfortunate STZ kits continues DML’s streak of excellent T-34 kits.

Thanks to Freddie Leung of Dragon Models USA for the review sample.

Sprue Breakout:

  • A 12x2 T-34 driver mounts, road wheel arms
  • B 21 T-34 40/41 turret roof and hull details
  • C 21 T-34 40/41 upper hull and details
  • C 19 T-34-85 details and gun barrel
  • D 6 T-34 Model 1942 Turret (pressed steel)
  • E 16 T-34 tie-downs and brackets
  • F 20 T-34 42 hull detail components
  • H 6 T-34 engine intake vents, driver’s hatch
  • H 14 T-34 41 turret front and details
  • J 3 Clear styrene
  • K 13 T-34 41 F-34 gun assembly
  • L 33 T-34 42 “Gayka” turret assembly
  • M 18x2 T-34 95 liter round auxiliary fuel tanks
  • N 4x2 T-34 spring towers
  • P 39x2 T-34 center-buffered ast steel wheels and suspension components
  • P 45 T-34 Krasnoye Sormovo hull details
  • P 4 T-34 rear grilles and stern plate
  • S 2 Twisted steel wire
  • W 10x2 T-34 Post-April 1942 rubber tired cast wheels
  • X 1 T-34 standard hull pan
  • Y 80 “Magic Track” waffle pattern track - flat link
  • Z 80 “Magic Track” waffle pattern track - toothed link
  • MA 83 Etched brass
  • MB 2 Etched brass
