Eduard 1/48 Polikarpov I-16 Type 10 Kit First Look

By Michael Benolkin

Date of Review August 2006 Manufacturer Eduard
Subject Polikarpov I-16 Type 10 Scale 1/48
Kit Number 8148 Primary Media Styrene/Photo-Etch
Pros Very nicely detailed kit Cons Nothing noted
Skill Level Intermediate MSRP (USD) $29.98

First Look

I-16 Kit
I-16 Kit
I-16 Kit
I-16 Kit
I-16 Kit
I-16 Kit

Polikarpov's design signature during the mid and late 1930s was stubby, barrel-shaped fighters. The primary machine during that era was the I-15 biplane. Like their barrel-shaped brothers on the other side of the world, the Grumman F3Fs, the I-15 was going to be transformed almost directly into a monoplane fighter, the I-16. In the transformation, the I-15's upper wing was deleted and the lower wing strengthened to carry the full load. With a wingspan one meter shorter than the I-15, the early I-16 was powered by the same 700hp M-25 radial engine as the late-model I-15. The I-16 also incorporated retractable landing gear which could be exchanged for retractable skis.

Armament for the I-16 Type 10 was a pair of 7.62mm machine guns in the top of the nose and another pair in the wings just outside the propeller arc. The Type 17 retained the nose-mounted machine guns, while the wing-mounted guns were replaced with 20mm cannons.

The I-16 saw combat on two fronts in the late 1930s, first in the Spanish Civil War and later with the Chinese against Japan. In Spain, the early Bf 109s flown by the Nationalists were surprised by the agile I-16 and suffered losses to the 'Rata' (Rat) as they nicknamed it. The Japanese forces were also surprised by the agile I-16 until they finally discovered and exploited the I-16's weaknesses.

By the time the Nazi violated the peace treaty between the Soviet Union and Germany, the I-16 was obsolete. Nonetheless, the I-16 soldiered on into 1943 before being completely phased out of service. One of the most famous tactics flown by Soviet pilots in 1941 was ramming their I-16s into the tails of German aircraft, then either limping back to base or parachuting to safety.

I rather like this unusual-looking aircraft as it resembles a 55 gallon drum with wings. I had enjoyed building the Hobbycraft 1/48 I-16 (later re-released by Academy) but I received several emails pointing out the inaccuracies in the kit. Perhaps, but since it was the only kit on the market, the discussion was moot. Until now.

Eduard has taken on the subject of the I-16 and it looks every bit as nice as the recent 1/32 Azur/Special Hobby I-16. At last, we have choices! In this release, Eduard has taken on the early Type 10 variant (there are more on the schedule).

Molded in olive drab styrene, the kit is presented on four parts trees, plus a tiny clear stub containing the windscreen. The kit is rounded out with a set of color photo-etched parts.

Construction begins with the cockpit and Eduard has reconstructed all of the various cranks and levers in photo-etch, including a photo-etch throttle quadrant. There would be lots of cranks in the aircraft as nothing was mechanized in the aircraft - the landing gear had to be manually cranked up and down.

Look at the color photo-etch. The instrument faces and placards are beautiful. The pre-colored seatbelts and shoulder harness are also quite nice. Talk about a time saver with excellent results every time!

The engine cowling louvers are done in photo-etch and are positionable. Many kits mold these louvers closed to avoid having engine detail to contend with, but Eduard provides an engine face for behind the louvers. It was common to keep the louvers closed when warming up the engine or descending with the power at idle to keep the engine from thermal shock.

The landing gear detail is as nice as I've seen for the subject in any scale, and the instructions clearly show the proper placement of the retraction cable that extends from the wheel well to the axle.

The kit also provides an optional photo-etched cockpit entry door.

Markings are provided for four specific aircraft:

  • I-16, Red Five Aerobatics Team, 1939
  • I-16, Unknown Unit, Ukraine, Summer 1941
  • I-16, Major General Ivan A. Lakeev, Hero of the Soviet Union, 1941
  • I-16, Red 4, Leningrad area, 1944

This is a beautiful kit with excellent details throughout. I've read some discussions about the shape/contour of the front of the cowling, and while I can see that it may not be as rounded in profile as it should, it isn't anything that a few minutes with a sanding stick wouldn't fix!

My sincere thanks to for this review sample!
